MT 200

$800.00 Price drop reminder
  • Brand: Symcot
  • Product Code: MT 200
  • Availability: 1000

Total $800.00
This product has a minimum quantity of 10
 Model MT 200
Dimension.(L×W×H)(mm) 2100x775x1100
Wheel base(mm) 1360
Min ground clearance (mm) 138
Seat height(mm) 810
Turning angle 48°
Min turning radius(mm) 2120
Front/rear sprocket teeth 17/42
Gearshift 5-forward
Fuel tank(L) 14
 Fuel Type Gasoline
Max. Load Capacity(kg) 150
Dead Weight(kg) 125
Displacement/Power(ml/kw): 185
Eco fuel consumption(L/100km) 2.1
Brake Mode Front Wheel Disc brake
Rear Wheel Disc brake
  Front Wheel Manual
Brake Operation Mode Rear Wheel kick
Wheel Rim Type Front aluminum wheel:       1.60×17
Rear aluminum wheel:          2.10×17
Tire type With tube
Front tire 90/70-17
Rear tire 140/70-17
Head light 12V  35W/35W
Winker 12V  10W
Batterymm Maintenance Free: 12V6.5AH    114×71×106

Engine type 1-Cylinder, 4-stroke, air-cool, built-in balancer
Engine Model 164FML
Start Electric+kick
Ignition CDI
Bore×Distance 63.5×62.2
Displacement(ml) 196
Compression rate 9.0:1
Magneto 12V 8head full phase
Oil capacity(ml) 1100
Spark plug D8TC
Spark clearance(mm) 0.6~0.7
Valve clearance(mm) 0.04~0.06
Lubriation Press+splash
Carburetor PZ30
Transmission Constant mesh
Clutch type manual, wet, multi-disc
Initial trans rate 3.333
Gearshift rates 1st: 2.769 ,2nd: 1.882,third; 1.400,forth: 1.130,fifth: 0.960
Final trans Chain
Rotation direction Facing shaft, unclock wise
Size(mm) 358×324×446
N.W.(kg) 31
Rated power 9.5KW(7500r/min±5%)
Max power 10KW(8000r/min±5%)
Max torque 14N·m(6000r/min)
Load Quantity 40HQ 105 units
Price USD800 FOB Jiangmen, China
