CGL200 DEPRETADOR

$500.00 Price drop reminder
  • Brand: DEPRETADOR
  • Product Code: CGL200 DEPRETADOR
  • Availability: 1000

Total $500.00
This product has a minimum quantity of 34
 Model CGL 200
Dimension.(L×W×H)(mm) 2030×770×1310
Wheel base(mm) 1270
Ground (mm) 200
Seat height(mm) 820
Turning angle 48°
Min turning radius(mm) 2040
Front/rear sprocket teeth 15/43
Gearshift 5-forward
Fuel tank(L) 12L
 Fuel Type Gasoline
Max. Load Capacity(kg) 150
Dead Weight(kg) 115
Displacement/Power(ml/kw): 200cc
Eco fuel consumption(L/100km) 2.1
Brake Mode Front Wheel:Disc brake
Rear Wheel:Drum brake
  Front Wheel:Manual
Brake Operation Mode Rear Wheel:kick
Wheel Rim Type Front wheel:        1.40×18 , aluminum
Rear wheel:        1.85×18, aluminum
Tire type With tube
Front tire 2.75-18
Rear tire 3.00-18
Head light 12V  35W/35W
Winker 12V  10W
Batterymm Jelly battery 12N7AH    150×60×130

Engine type 1-Cylinder, 4-stroke, air-cool, OHC
Engine Model 163FML-B
Start Electric+kick
Ignition CDI
Bore×Distance 63.5*62.2
Displacement(ml) 196
Compression rate 9.21
Magneto 12V 8head full phase
Oil capacity(ml) 1100
Spark plug D8EANGK
Spark clearance(mm) 0.6~0.7
Valve clearance(mm) 0.04~0.06
Lubriation press+splash
Carburetor PZ30
Transmission Constant mesh
Clutch type Manual, multi-disc
Initial trans rate 3.333
Gearshift rates 1st: 2.769 2nd: 1.882 3rd: 1.400 4th 1.130fifth: 0.960
Final trans Chain
Rotation direction Facing shaft, unclock wise
Size(mm) 388×324×446
N.W.(kg) 31
Rated power 10.2KW(8000r/min±5%)
Max power 10.8KW(8000r/min±5%)
Max torque 13N·m(7000r/min)

Load Quantity 40HQ:175 sets in CKD
Load Quantity 40HQ:126 units in SKD(double package)
